Deep groove radial bearings are manufactured as open type bearings for oil or grease lubrication. They are also available with metal shields and/or seals for use where moderate contamination is present in the operation.
applications
Transmissions
Electric motors and generators
Electrical appliances
Pumps and compressors
Blowers and fans
Speed changers
Gearboxes and drives
Woodworking machinery
Lawn and garden equipment
compliances
0
caution
If very small bearing loads are expected, please contact Applied® for selection of an appropriate bearing
Preload Level
None
Inner Ring Width
10 mm
I.D.
12 mm
icNumber
7695873
Radial Internal Clearance
C3
No. in Set
Single Bearing
Inch/Metric
Metric Bore
Bearing Type
Radial
Radial Internal Clearance Specification
Greater Than Normal Clearance
Cage Type
Metal
Static Load Rating [Max]
686 lbf
Limiting Speed - Grease
22000 rpm
Precision
Standard
Seal Material
Rubber
Dynamic Load Rating
1530 lbf
Rows of Balls
Single
Cage Material
Pressed Steel
Seal Type
Non-Contact Seals
Locking Device
No Locking Device
Capacity
Standard Capacity
O.D.
32 mm
Corner Radius [Min]
0.6 mm
Limiting Speed - Oil
N/A
Snap Ring
No Snap Ring
Lubricant
Mul-Temp SRL
Precision Level
Standard (ABEC 1)
Bore Type
Round Bore
Outer Ring Width
10 mm
Contact Angle
0°
Ball Material
Steel
Material
Steel
O.D. Type
Straight
Enclosure
Double Sealed
Weight
0.077 LB
EAN or UPC
29176013812
